Foundry Core Vent

M.S Slotted Vent

MS Slotted vents are made from the material of EN1A. These Vents are supplied with the Bright nickel plating for better corrosion resistance. This Vent can be Suitable to use at higher temperature.

SIZE Ø 3 4 5 6 8 10 12 14 16 18 20 25
LENGTH 7 7 7 7 7 7 7 7 7 7 7 7
10 10 10 10 10 10 10 10 10 10 10 10
FEATURE :
  • Material : EN1A
  • Size Available : 3mm to 25mm (Other as per customers specification)
  • Slot or Cutter Size : 0.3mm (Other on request)
  • Height : 7mm & 10mm (Other on request)
